Gen1 Needleless Needle Free Negative High Pressure Compatibility Infusion 4mm Y Type

FOB Reference Price:Get Latest Price
US $0.3-0.33 / Pieces | 6000 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Properties:
Injection & Puncture Instrument
Place of Origin:
Taiwan
Brand Name:
Chi Feng
Model Number:
11C001
pressure type:
negative
ID:
4.07
Product name:
needle free negative high pressure compatibility infusion 4mm Y type
Material:
Medical Grade PVC
Name:
Needle Free
Color:
Blue
Certificate:
ISO13485
Application:
Medical injection
Size:
Customized Size
Feature:
Negative Pressure
Supply Ability
Supply Ability:
30000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Carton : 36*36*30 cm
500 pcs in a bag
6,000 pcs in a carton
G.W. 12KGW
Port
Keelung, Taipei Taoyuan
Lead Time :
7~30 days
Drawing

11C001 is For 4 mm tubing.

Product Overview
.Comply with ISO 594 standards.
.Simple mechanism design.
.Easy to clean swabable surface.
.High pressure compatibility.
.Pass biocompatibility test.
.Patented model designs with multiple countries' patents.
Product Features
Comply with the ISO 594 standards, and can comply with most other infusion products.

Simple mechanism structure, only three components for assemble, significantly reduce the rate of lose effectiveness.

The swabable surface design to fit most clinical practices, easy to swabbed and no residual on the surface.

Resist high pressure from inserting up to 7kg/cm^2.

Metal components are not included, MRI compatibility.


Product Introduction
Product IntroductionNeedless infusion devices develop and produce by Chifeng plastic, and acquired patents from multiple countries. The Gen 1 needleless series did not contain any metal material, The fitting part follows the ISO 594 standards and completes the test, it can fit any infusion products who follow the ISO 594 standards. As much as possible reduce the application of force of linking, in order to avoid the fitting part self-dropping by external force or internal pressure.

Housing and septum material are using medical grade polycarbonate and have passed medical grade silicone, bio-caompatibility test, lipid and alcohol resistance. The structure of housing passed the blood compatibility test, when blood stream passes the vavle, reduce the hemolysis problem. Silicone seal can activation up to 200 actuations, and the swabable surface is sealed arround the top of housing, to create first microbial barrier protection. According to the fluorescein dye test, when disconnect and swab the surface, the fluorescein dye did not residual on the swabable surface.

The Chifeng Gen 1 needleless series can also use in the high pressure infusion therapy, when the insert part are not connecting, it can resist the pressure maximum 7kg/cm2 from the pipeline, when connect, it can resist maximum 24kg/cm2 (350PSI).
Specification

Products name
Chifeng Gen 1 needleless infusion connector series

Materials
Medical grade polycarbonate and medical grade silicone, biocompatibility test pass.

Pressure type
Negative pressure.

Functional activation
Up to 200 actuations.

Flow rate
150 ml / min (at 36 inch head height)

Residual volume
0.3 ml

Reflux Volume
0.3 ml

Flush Volume
1.5 ml

Disconnect force
<1kg

Pressure leakage
Up to 7kg/cm2 (Disconnection) / 24kg/cm2 (350PSI)(Connection)

Drug Compatibility
.Alcohol
 Compatible : Yes.
 Note : None.
​.Lipid
 Compatible : Yes.
​ Note : None.
Product Literature

Visit our website

http://www.c-feng.com.tw/

Needleless infusion on-line catalog
